Industrial
ELEKTRISCH INS-F LV
High Performance Electrical Insulation Fluid
NORC ELEKTRISCH INS-F LV is a high performance and high efficiency electrical insulation fluid that was developed to maxim...
Industrial / Transformer Oil
ELEKTRISCH INS-F
High Performance Electrical Insulation Fluid
NORC ELEKTRISCH INS-F is a high performance and high efficiency electrical insulation fluid that was developed to maximize performance and productivity. It was specially engineered using the highest quality raw materials to withstand energy spikes in...
- Catalogue source
- Description page 206; technical page 207
NORC ELEKTRISCH INS-F is a high performance and high efficiency electrical insulation fluid that
was developed to maximize performance and productivity. It was specially engineered using the
highest quality raw materials to withstand energy spikes in extremely hot and cold climates.
NORC ELEKTRISCH INS-F is produced using Sulphur free base stocks to prevent corrosion. Since it is free from
carcinogenic poly-nuclear aromatics (PNAs), the product is essentially non-toxic. The special negative gassing
effects and increased flash point reduce the risk of fire and explosion.
NORC ELEKTRISCH INS-F is a fully inhibited oil ideal for use in larger power and distribution transformers operating at
peak capacity as well as free-breathing units, pad mount and pole mount transformers. It is designed for Type I & Type
II applications.
was developed to maximize performance and productivity. It was specially engineered using the
highest quality raw materials to withstand energy spikes in extremely hot and cold climates.
NORC ELEKTRISCH INS-F is produced using Sulphur free base stocks to prevent corrosion. Since it is free from
carcinogenic poly-nuclear aromatics (PNAs), the product is essentially non-toxic. The special negative gassing
effects and increased flash point reduce the risk of fire and explosion.
NORC ELEKTRISCH INS-F is a fully inhibited oil ideal for use in larger power and distribution transformers operating at
peak capacity as well as free-breathing units, pad mount and pole mount transformers. It is designed for Type I & Type
II applications.
- Designed for Type I & Type II applications
- Extended oil life
- Excellent protection against corrosion
- Excellent low temperature viscometric properties
- Free from Sulphur
- Less breakdowns and maintenance expenses
- Non-toxic formulation
- Outstanding performance
- Proper heat transfer inside transformers
- Reduce the risk of fire and explosion
- Suitable for use in extreme hot and cold climates
- CSA C50 (CLASS A & CLASS B)
- CSA C50-08 (TYPE III & TYPE IV)
- ASTM D3487
- IEC 60296
- HYDRO ONE M-104
Technical Details
Catalogue DataTECHNICAL DETAILS
205 Litres ℮
PROPERTY
UNIT
Kg / L
Cst
Cst
Cst
Cst
⁰C
⁰C
0.835
9.2
2.8
53
1230
170
- 60
Specific Gravity @ 15⁰C
Kinematic Viscosity @ 40⁰C
Kinematic Viscosity @ 100⁰C
Kinematic Viscosity @ 0⁰C
Kinematic Viscosity @ -40⁰C
Flash Point
Pour Point
CSA C50 (CLASS A & CLASS B)
CSA C50-08 (TYPE III & TYPE IV)
ASTM D3487
IEC 60296
HYDRO ONE M-104
ELEKTRISCH
INS-F
* Further Values
Available Upon
Request
Technical data is indicative catalogue information. Confirm the latest official data sheet before use.
Standard Packaging
- 205 Litres
